Flux AI: Terror Elevator

Terror Elevator Flux Artworks

This image is a technical drawing of the Terror Elevator ride. It includes detailed front, side, and top views with accurate dimensions. The front view features a centered bi-fold door at a height of 2100mm. The side view illustrates a ramp leading to a raised floor that is 500mm above the ground. The top view shows a cabin that measures 3000mm x 3000mm within a 3500mm outer cube, highlighting the door location and wall positioning. Dimensions are clearly marked for reference, ensuring thorough understanding of the structure.
N

Technical Drawing of the Terror Elevator Ride: Front, Side, and Top Views with Dimensions

side view
Terror Elevator
Top view
